I. Usage

Paper weight: 13-30gsm

Raw material: waste tissue paper,newspaper, printing paper

Finish paper: rolling tissuepaper, napkin paper, facial paper,

Handkerchief paper.

II. Main crafts parameters

1、Pulp : Wood pulp plate,waste paper

2、Feeding pulp concentration: 0.3-0.9‰

3、beating degrees : 30-38°SR

4、paper sheet dryness:

Come out from wire case : 18-20％

Before go through MG cylinder : 36-40％

Come out from MG cylinder : 90-94％

Finish tissue : 90-94％

5、Lateral shrinkage : 8-10％

6、Day running hours: 22 hours

7、Papermaking rate : 94％

8、Yield : 95％

9、Touch roll line pressure:40KN/m

10、other parameter

AC voltage : 380V；50Hz

Control voltage: 220/24V

Water pressure: 0.25Mpa; workingpressure: 0.2Mpa

Compressed air source pressure:0.6Mpa; working pressure: 0.4Mpa

Steam pressure : 0.6Mpa ; workingpressure：0.3Mpa

Vacuum suction tank: 20-40Kpa

Water requirement: pure color,remove impurities, PH value 6.8

III. Main technical parameters

1、Papermaking quantitative:13-30g/㎡ high wrinkles toilet paper

2、Net width of paper :1575mm

3、Designed speed : 210m/min

4、Working speed: 170-190m/min

5、Nominal capacity : 4-5T/D

6、Rail Gauge: 2400mm

7、Wrinkling rate : 22％

8、Transmission : Y-type ACmotor drive partly, frequency control

MG cylinder motor: 37kw

Roll-cylinder motor: 3kw

9、Arrangement : Single-layer,the left and right hand arrangement
